seca mBCA Alpha

seca mBCA Alpha

seca mBCA Alpha

Medical Body Composition Analyzer with gold standard validation

  • Move beyond the limitations of BMI and gain medically validated insights into your patient’s body composition in just seconds
  • Unmatched precision through gold standard validation: whole-body MRI for skeletal muscle mass and the 4C model for fat mass
  • All validation studies have been published in peer-reviewed journals, including the European Journal of Clinical Nutrition
  • Comprehensive, personalized normal ranges based on over 3,000 multiethnic subjects
  • Specially developed formulas for children over 5 years and 1.30 m as well as people over 65 years and patients with obesity



Imagine seeing inside your patient’s body – clearly understanding what it’s made of and what’s putting health at risk. With the seca mBCA Alpha, that insight is just a step away. In seconds, it delivers a clinically validated, in-depth analysis of body composition – clear, precise, and easy to understand. With meaningful metrics like skeletal muscle mass, visceral fat, and phase angle, you gain the clarity to guide therapy, personalize care, and make informed decisions – moving far beyond BMI and assumptions.

Learn more


seca mBCA Alpha

Order code ON IGM INT NN

  • BIA platform mBCA 554
  • BIA handle seca mBCA 545

Videos


Product information

Technical product data and support

Technical Data

Display type: 4.3" tiltable and rotatable touchscreen
Approval class: III (3)
Capacity: 800 lbs, 360 kg
Graduation (lbs): 0.1 lbs
Graduation (g): 50 g
Power supply: Power adapter
Measure (W x H x D): 23.6 x 2.8 x 18.4 in , 600 x 1,233 x 653 mm
Net weight: 45.8 lbs , 20.8 kg
Interfaces: Ethernet, WLAN
Ports: USB for bar code scanner
Measurement time: 24 seconds
Measurement segment: Right arm, left arm, right leg, left leg, right half of body, left half of body, torso
Measurement method: 8-point Bioelectrical Impedance Analysis
Measurement frequencies: 1; 2; 5; 10; 20; 50; 100; 200; 500 kHz
Measurement current: 100 µA
Functions and Properties: Backlighting, Acoustic signals can be activated, BF / BW-Measurement, Wireless interface, BMI, Auto-BMI, Damping, Autom. Weighing range switch-over, RESET, Auto-clear, Clear, Auto-HOLD, HOLD, Pre-TARE, TARE
Manual
seca_assin_545_544_542
seca_assin_545_544_542 seca_assin_545_544_542
Manual
seca_man_555_554_552_de_en_fr_es
seca_man_555_554_552_de_en_fr_es seca_man_555_554_552_de_en_fr_es
